Jaw Couplings – Hub Half Taper Lock
TransDrive jaw coupling hubs with taper lock design are precision-machined to ensure smooth contact surfaces, accurate alignment, and excellent rotational balance. Their modular construction allows for compatibility across multiple coupling models, delivering both flexibility and cost-efficiency in various drive system configurations.
These hubs are available pre-bored and keyed to suit standard IEC motor shaft sizes, with taper fit options to accommodate non-standard shafts. Built to perform in demanding environments, TransDrive hubs offer strong resistance to water, dust, oil and grease, ensuring long-lasting and reliable operation in a wide range of industrial applications.
Product Specifications
| Size TF/ TWNS | Bush | A | B | E | J | G | C | D | K | T | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Max. Bore | ||||||||||||
| mm | Inch | Taper Lock | T – Type 1 | ||||||||||
| L100 | 1108 | 28 | 1 1/8 | 65 | 78 | 65 | 27 | 44 | 18 | 10.5 | 23.5 | 29 | 65 |
| L110 | 1210 | 32 | 1 1/4 | 84 | 96 | 84 | 35 | 48 | 22 | 13.5 | 26.5 | 38 | 75 |
| L150 | 1210 | 32 | 1 1/4 | 96 | 111 | 96 | 35 | 55 | 25 | 11.5 | 26.5 | 38 | 78 |
| L190 | 1610 | 42 | 1 5/8 | 115 | 129 | 102 | 45 | 63 | 25 | 7.5 | 26.5 | 38 | 78 |
| L225 | 2012 | 50 | 2 | 127 | 142 | 108 | 45 | 63 | 25 | 14.5 | 33.5 | 42 | 92 |
