FL Series
The TransDrive FL series is an earlier style and less commonly used leaf chain. The FL/ FLC leaf chain is a light duty that uses single interlacing. It is most commonly used in the UK and to a lesser extent in Europe.
Product Specification
| Chain No. | Pitch P mm | Lancing | Plate | Pin | Ultimate Tensile Strength Q0 kN mm | Average Tensile Strength Q0 kN mm | Weight Per Metre q kg/m | ||
|---|---|---|---|---|---|---|---|---|---|
| Depth h2 max mm | Thickness T max mm | Diameter d2 max mm | Length L max mm | ||||||
| FL644 | 5.940 | 4 X 4 | 4.7 | 0.60 | 1.85 | 6.6 | 6.5/1477 | 7.8 | 0.40 |
| FL666 | 6 X 6 | 9.3 | 9.75/2216 | 11.8 | 0.80 | ||||
| FL688 | 8 X 8 | 12.0 | 13.0/2955 | 15.6 | 1.20 | ||||
| FL523 | 8.000 | 2 X 3 | 6.3 | 1.00 | 2.31 | 6.7 | 7.00/1575 | 7.4 | 0.50 |
| FL844 | 4 X 4 | 6.9 | 0.73 | 7.9 | 10.0/2273 | 12.1 | 1.00 | ||
| FL944 | 9.525 | 4 X 4 | 8.7 | 1.04 | 3.28 | 10.4 | 21.0/4724 | 24.7 | 0.43 |
| FL945 | 4 X 5 | 11.5 | 21.0/4724 | 23.0 | 0.50 | ||||
| FL966 | 6 X 6 | 14.9 | 31.0/7045 | 36.8 | 0.65 | ||||
| FL988 | 8 X 8 | 19.0 | 42.00/9450 | 46.2 | 0.87 | ||||
| FL1222 | 12.700 | 2 X 2 | 8.2 | 1.00 | 3.58 | 7.0 | 11.43/2598 | 13.6 | 0.19 |
| FL1223 | 2 X 3 | 10.2 | 2.03 | 4.45 | 12.8 | 20.0/4545 | 23.8 | 0.61 | |
| FL1244 | 4 X 4 | 10.2 | 1.70 | 4.45 | 16.7 | 44.0/1000 | 52.3 | 0.83 | |
| FLC545 | 15.875 | 3 X 4 | 12.7 | 1.85 | 5.08 | 15.3 | 40.4/9181 | 44.4 | 0.99 |
| FLC556 | 4 X 5 | 19.2 | 51.3/12340 | 59.7 | 1.27 | ||||
| FLC567 | 5 X 6 | 22.7 | 67.6/15363 | 74.3 | 1.54 | ||||
| FLC567 | 6 X 8 | 26.8 | 80.80/18176 | 89.0 | 1.82 | ||||
| FLC578 | 7 X 8 | 30.8 | 90.00/20250 | 99.0 | 2.10 | ||||
